Baja Paduan Finishing Wireline Tools Wire Finder Wireline Slickline Pulling Tools
Kontak Person : LEE
Nomor telepon : 86-13659253658
Ada apa : +8613659253658
| Minimum Order Quantity : | 1 set | Harga : | USD 1-10000/set |
|---|---|---|---|
| Packaging Details : | Pollywood | Delivery Time : | 30-50 days |
| Payment Terms : | L/C,T/T,D/P | Supply Ability : | 10 set/month |
| Place of Origin: | China | Nama merek: | ZZ TOP OIL TOOLS |
|---|---|---|---|
| Sertifikasi: | ISO, API | Model Number: | Hay Pulley |
|
Informasi Detail |
|||
| Product: | 16" Hay Pulley | Material: | Alloy Steel |
|---|---|---|---|
| Size: | 16 inch | Application: | Oil & Gas Well Downhole Operation |
| Wire Range: | 0.092" - 0.140" | Working Condition: | Oil & Gas & H2S service |
| Usage: | Wireline Operation /Slick line Service | Delivery: | 20-30 days |
Deskripsi Produk
Alat Wireline 16 Inch Hay Pulley Untuk Wireline 0.108 "- 0.140"
Hay Pulley adalah komponen alat kabel untuk layanan kabel & slickline. The Hay Pulley is used to control and manipulate the direction of the wireline from a horizontal positon to a vertical position and generally installed at the wellhead on the lubricator to reduce side pull force and to avoid lateral loading of the lubricator during heavy jarring operations.
Pulley jerami dirancang untuk menahan beban kawat Slickline dan tali, selain keausan kehidupan di situs rig.Pulleys dibuka oleh mekanisme sederhana yang memungkinkan pemasangan mudah kawat ke Hay Pulley. Pin sheave memiliki perlengkapan untuk menerima bantalan lantai ringan jika diperlukan.
SpesifikasiPulley jerami
| Ukuran Nominal | Jangkauan kabel | Beban Keamanan |
| 10" | 0.092"-0.125" | 2500kg |
| 11 | 0.092" - 0.125" | 2500kg |
| 12" | 0.092" - 0.125" | 2500kg |
| 13 " | 0.092"-0.125" | 2500kg |
| 14" | 0.092" - 0.125" | 2500kg |
| 16 ¢ | 0.092"-0.187 | 5000kg |
